| Book size max.: |
11.75" x 16.5" (300mm x 420mm)
|
| Book size min.: |
5.5" x 6.75" (140mm x 170mm)
|
| Book thickness max.: |
1 3/4" (45mm) |
| Book thickness min.: |
3/32" (2mm) |
| Cover size max.: |
16.5" x 25.25" (420mm x 640mm)
|
| Cover size min.: |
6.75" x 11.50" (170mm x 290mm)
|
| Cover weight: |
20 lbs. to 135 lbs.* (*may require prescoring)
|
| Glue temp. max.: |
390° F (200° C) |
| Glue temp. min.: |
302° F (150° C) |
| Speed: |
1,000 to 2,000 cycles per hour |
| Length: |
106.3" (270cm) |
| Width: |
57.0" (145cm) |
| Height: |
63" (160cm) |
| Weight: |
3520 lbs. (1,600kg) |
| Power: |
220V*/3 Phase/20Amp/60Hz (380V/3 Phase/12Amp/50Hz)
|
| Warm up time: |
30 minutes |
| Scoring/Roughing: |
Yes |
| Notching: |
Yes |
| Milling: |
Yes |
| Built in jogger: |
Yes |
| Paper waste collection: |
Yes |
| Fumes extractor: |
built in |
| Set counter: |
Yes |
| Number of clamps: |
4 |
| Side Gluing: |
Yes |
